Permanently mark wires and cables with the low-smoke, halogen-free B-7641 polyolefin label material. Pre-sized to fit most wire and cable assemblies. Print with a Brady handheld label maker.
| Part Number | M4C-125-7641-YL |
| Product Number | 170849 |
| UPC | 888434592762 |
| UOM | Cartridge of 66 in |
| Brand Name | Brady |
| Application | Electrical Labeling, Wire and Cable Labeling |
| Approval/Compliance (EMEA) | BS-6853 (1999) Vehicle Category 1A, EN-45545-2, requirement 24, Vehicle Category HL3, Zero Halogen |
| Brady Material Number | B-7641 |
| Color | Black on Yellow |
| Continuous or Die-cut | Continuous |
| Diameter as Supplied (imperial) | 0.125 in |
| Diameter as Supplied (metric) | 3.18 mm |
| Dimensions (imperial) | 0.235 in H x 5.5 ft L |
| Dimensions (metric) | 5,97 mm (H) x 1,68 m (L) |
| Enables Industry Compliance (North America) | ASTM D 257, ASTM D 2671, ASTM D 2671C, ASTM D 570, ASTM D 635, ASTM D 638, ASTM D 792, BS6853 (1999) Vehicle Category 1a, European Standard EN 45545-2, Requirement Set R22/R23, Vehicle Category HL3, Halogen Free (DIN VDE 0472 Part 815), MIL-M-81531, MIL-STD-202, MIL-STD-202G, SAE-AS-81531 |
| Finish | Matte |
| Height (imperial) | 0.235 in |
| Height (metric) | 5.97 mm |
| Label Properties | Heat Shrink |
| Length (imperial) | 5.5 ft |
| Length (metric) | 1.68 m |
| Material | Heat-shrink Polyolefin |
| Material Properties | Flame-retardant, Heat-shrinkable, Low-smoke, Zero-halogen |
| Material Type | Polyolefin |
| Maximum Service Temperature (°C) | 105 °C |
| Maximum Service Temperature (°F) | 221 °F |
| Maximum Wire Diameter (imperial) | 0.11 in |
| Maximum Wire Diameter (metric) | 2.79 mm |
| Maximum Wire Gauge | 16 AWG |
| Minimum Service Temperature (°C) | -55 °C |
| Minimum Service Temperature (°F) | -67 °F |
| Minimum Wire Diameter (imperial) | 0.062 in |
| Minimum Wire Diameter (metric) | 1.57 mm |
| Minimum Wire Gauge | 20 AWG |
| Primary Noun, Basic Function.1 | Sleeve |
| Print Technology | Thermal Transfer |
| Printer Compatibility | BMP41, BMP51, BMP53, M511, M410, M510 |
| Printer and Label Applications | Wire & Cable |
| Printer supply or Pre-printed | Printer supply |
| Recovered Diameter (imperial) | 0.063 in |
| Recovered Diameter (metric) | 1.60 mm |
| Recovered Wall Thickness (imperial) | 0.025 in |
| Recovered Wall Thickness (metric) | 0.64 mm |
| Resistance Properties | Chemical-resistant, Corrosion-resistant, Humidity-resistant, Self-Extinguishing, UV-resistant, Weather-resistant |
| Ribbon Series | R6000HF |
| Roll Length (imperial) | 5.5 ft |
| Roll Length (metric) | 1.68 m |
| SAP B-Number | B-7641 |
| SAP Local Description | M4C-125-7641-YL |
| Service Temperature Range (°C) | -55 °C - 105 °C |
| Service Temperature Range (°F) | -67 °F - 221 °F |
| Shrink Ratio | 2:1 |
| Sleeve Size (imperial) | 0.125 in Dia x 5.5 ft L |
| Sleeve Size (metric) | 3.18 mm Dia x 1.68 m L |
| Smart Cell | Yes |
| Trade Name | PermaSleeve |
| Wire Diameter Range (imperial) | 0.062 in to 0.11 in |
| Wire Diameter Range (metric) | 1.57 mm to 2.79 mm |
| Wire Gauge Range | 20 AWG - 16 AWG |
| Contains CA PROP 65 Substance | Yes Contains-Label not req. |
| Contains CA PROP 65 Substance (Y/N) | N |
| Contains Heavy Metal(s) | No - Does not contain |
| EU RoHS Compliance | Pass 2011/65/EU(Pass 2015/863) |
| EU RoHS Compliant | Yes |
| SDS Safety Data Sheet required | No = MSDS/SDS is not required |
