Brady Accessory - 170378
- Part #:
- 170378
Product Description
All-Purpose Cable Lockout Green with 8 ft Sheathed Steel Cable
30 Years of Service
Huge Inventory / Fast Shipping
Easy 30 Day Return Policy
Secured Transaction
All-Purpose Cable Lockouts help you navigate tight or tricky spaces to lock out several energy isolation points at once as well as difficult-to-secure valves and panels.
| Part Number | 170378 |
| Product Number | 170378 |
| UPC | 888434587492 |
| UOM | Each |
| Brand Name | Brady |
| Application | Lockout Tagout |
| Approval/Compliance (EMEA) | OSHA 1910.147 |
| Cable Color | Clear |
| Cable Diameter (imperial) | 0.125 in |
| Cable Diameter (metric) | 3.18 mm |
| Cable Finish/Coating | PVC |
| Cable Included? | Yes |
| Cable Length (imperial) | 8 ft |
| Cable Length (metric) | 2.44 m |
| Cable Material | PVC Coated Steel |
| Color | Green |
| Conductive | No |
| Depth (imperial) | 2.673 in |
| Depth (metric) | 67.89 mm |
| Dimensions (imperial) | 7.172 in H x 1.441 in W x 2.673 in D |
| Dimensions (metric) | 36,59 mm (W) x 182,17 mm (H) x 67,89 mm (D) |
| Enables Industry Compliance (North America) | OSHA 1910.147 |
| Height (imperial) | 7.172 in |
| Height (metric) | 182.17 mm |
| Industry | Beverage processing, Chemical, Automotive, Construction, Energy utilities, Food processing, Manufacturing, Oil & gas, Process, Pulp & paper |
| Material | ABS, Glass-filled Nylon |
| Maximum Number of Padlocks | 4 |
| Maximum Service Temperature (°C) | 100 °C |
| Maximum Service Temperature (°F) | 212 °F |
| Maximum Shackle Diameter (imperial) | 0.354 in |
| Maximum Shackle Diameter (metric) | 8.99 mm |
| Minimum Service Temperature (°C) | -40 °C |
| Minimum Service Temperature (°F) | -40 °F |
| Minimum Shackle Clearance (imperial) | 0.375 in |
| Minimum Shackle Clearance (metric) | 9.53 mm |
| Number of Holes | 4 |
| Primary Noun, Basic Function.1 | Cable Lockout |
| Risk Type | Electrical Risk, Mechanical Risk |
| SAP Local Description | APCLO,GRN 8FT (2.4M) W_PVC COATED CABLE |
| Service Temperature Range (°C) | -40 °C - 100 °C |
| Service Temperature Range (°F) | -40 °F - 212 °F |
| Width (imperial) | 1.441 in |
| Width (metric) | 36.59 mm |
| Contains CA PROP 65 Substance | No - Does not contain |
| Contains CA PROP 65 Substance (Y/N) | N |
| Contains Heavy Metal(s) | No - Does not contain |
| EU RoHS Compliance | Pass 2011/65/EU(Pass 2015/863) |
| EU RoHS Compliant | Yes |
| SDS Safety Data Sheet required | No = MSDS/SDS is not required |
